Description
- Horizontal windlasses
- Base in anodized aluminum in hard oxide
- Integrated sensor and magnet for chain counter
- Manual Free-Fall system
- IP67 watertight motor
Easy Installation. The vertical motor allows for extremely simple and quick installation.
| Eagle | 700 W | 7 – 10 m | 23 – 33 ft |
| Eagle | 1000 W | 10 – 13 m | 33 – 43 ft |
| Eagle | 1400 W | 12 – 15 m | 39 – 49 ft |
| Gypsy and Drum | Ø 130 mm / 5″ 1/8 |
| GYPSY | 6 mm | 8 mm – 5/16″” | 10 mm – 3/8″ | |||||
| CHAIN | 6 mm | 6 mm | 8 mm | 8 mm | 5/16″ | 5/16″ | 10 mm | 3/8″ |
| DIN 766 | ISO | DIN 766 | ISO | G4 | BBB | ISO (P.30) | G4 |
Supplied accessories standard
| Contactor units | Technopolymer handle | |||||||||||||
|
Optional accessories
|
Hydraulic magnetic |
UP/DOWN |
Foot |
handheld |
Chain |
Radio remote |
| Standard version | E3 1000 D | |
| Motor power | 1000 W | |
| Motor supply voltage | 12 V | 24 V |
| Maximum pull | 1250 Kg 2756 lb |
1250 Kg 2756 lb |
| Maximum working load | 390 Kg 860 lb |
490 Kg 1080 lb |
| Working load | 130 Kg 287 lb |
160 Kg 353 lb |
| Current absorbtion @ working load (1) | 140 A | 80 A |
| Maximum chain speed (2) | 37,6 m/min 123.4 ft/min |
47,8 m/min 156.8 ft/min |
| Maximum chain speed @ working load (2) | 17,8 m/min 58.4 ft/min |
20,9 m/min 68.6 ft/min |
| Weight | 23,5 Kg 51.8 lb |
23,5 Kg 51.8 lb |
| 1) | After an initial period of use |
| 2) | Measurements taken with a gypsy for a 8 mm chain |
Dimensions
E3 1000/1000D
Deck thickness:
25÷50 mm (31/32 ÷1″ 31/32)
On request, shaft and studs can be supplied for greater deck thicknesses.
Dimensions in mm (inch)
Supplied accessories standard
| Contactor units | Technopolymer handle | |||||||||||||
|
Optional accessories
|
Hydraulic magnetic |
UP/DOWN |
Foot |
handheld |
Chain |
Radio remote |
