Description
CLAMCLEAT CL2222AN Hard Anodized
Clamcleat CL222 is an elegant design in aluminium with a hard anodised finish. The rope drops down into the teeth. It can be fitted to all flat and curved surfaces, using rivets, countersunk (flathead) screws or bolts. CL222 can also be sewn, riveted or bolted onto webbing or fabric.
CL222AN has a hard anodised finish to give a hard wearing surface.
CL222 Racing Mini
Technical Details Metric Imperial
Rope Diameter 3 – 6mm 1/8 – 1/4″
Material Aluminium Aluminium
Hole Centres 36mm 1 7/16″
Length 48mm 1 7/8″
Width 15mm 19/32″
Height 21mm 13/16″
Bolt Size M4 #8-32. 5/32″
Screw Size 4.2 No 8
Weight 16gms 0.6oz
The purchaser is responsible for choosing the correct product for its particular application.
Not to be used for lifting Humans.
